Hikvision – Security IP Camera 4MP CMOS Turret CCTV IP Camera Outdoor/Indoor

Description

Origianl Hik Security IP Camera DS-2CD1341-I 4MP CMOS Turret CCTV IP Camera

Outdoor/Indoor with Night Version 100ft IR

Key Feature

1/3″ progressive scan CMOS
Up to 4.0 megapixel
2.8 mm/4 mm/6 mm fixed focal lens
Up to 30 m IR range
Dual stream
Digital WDR (Wide Dynamic Range)
3D DNR (Digital Noise Reduction)
PoE (Power over Ethernet)
IP67
Mobile monitoring via Hik-Connect or iVMS-4500
4MP
1080p Specification
 Camera
Image Sensor : 1/3″ progressive scan CMOS
Min. Illumination : Color: 0.01 Lux @(F1.2, AGC ON), 0 Lux with IR
Shutter Speed : 1/3 s to 1/100, 000 s, support slow shutter
Lens :   2.8 mm @ F2.0, horizontal field of view 105.8°, 4 mm @F 2.0, horizontal field of view 83.6°, 6 mm @F 2.0, horizontal field of view 55°
Lens Mount : M12
Day &Night : IR cut filter with auto switch
3-Axis Adjustment  : Pan: 0° to 360°, tilt: 0° to 75°, rotation: 0° to 360°
DNR (Digital Noise Reduction) : 3D DNR
WDR (Wide Dynamic Range) : Digital WDR
3D DNR
Compression Standard
Video Compression : Main stream: H.264+/H.264 ; Sub stream: H.264/MJPEG
H.264 Type : Main Profile/High profile
Video Bit Rate : 32 Kbps to 16 Mbps
Max. Resolution : 2688 * 1520
Main Stream : 50Hz: 20fps @(2688 * 1520), 20fps @(2304 * 1296), 25fps @(1920 * 1080, 1280 * 720)
              60Hz: 20fps @(2688 * 1520), 20fps @(2304 * 1296), 30fps @(1920 * 1080, 1280 * 720)
Sub-stream :  50Hz: 25fps @(640 * 360, 352 * 288) ; 60Hz: 30fps @(640 * 360, 352 * 240)
Image Settings : Brightness, saturation, contrast, sharpness are adjustable via web browser or client software
Day/Night Switch : Support auto, scheduled
Others : Mirror, BLC (area configurable), region of interest (support 1 fixed region)
Network
Network Storage : NAS (NFS, SMB/CIFS)
Detections : Motion detection
Alarms : Video tampering, network disconnected, IP address conflicted
Protocols : TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
Standard : ONVIF (PROFILE S, PROFILE G), PSIA, CGI, ISAPI
General Function : Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
 4
Interface
Communication Interface : 1 RJ45 10M/100M self-adaptive Ethernet port
POE
General
Operating Conditions : -30 °C to 60 °C (-22 °F to 140 °F), humidity: 95% or less (non-condensing)
Power Supply : 12 VDC ± 25%, PoE (802.3af)
Power Consumption : Max. 4 W/6.5 W (PoE)
Ingress Protection : IP67
IR Range : Up to 30 m
Dimensions : 69.1 mm * 66 mm * 172.7 mm ( 2.7″ * 2.6″ * 6.8″)
Weight : 500g(1.1 lb    .)

SPECIFICATIONS

Item specifics
  • Supported Mobile Systems:Windows Mobile,Android
  • High Definition:4.0 Megapixels
  • Alarm Action:FTP Photo
  • is_customized:Yes
  • Technology:Infrared
  • IR Distance(m):100ft
  • Lens (mm):2.8mm
  • Network Interface:RJ-45 10/100Mb Ethernet Slot
  • Viewing Angle :75°
  • Supported Operating Systems:Windows Vista,Windows 7
  • Minimum Illumination(Lux):Color: 0.01 Lux @(F1.2, AGC ON), 0 Lux with IR
  • Model Number:DS-2CD1341-I
  • Installation:Ceiling
  • Special Features:Waterproof / Weatherproof
  • Power Supply:With POE
  • Sensor:CMOS
  • Type:IP Camera
  • Power Supply(V):DC 12V
  • Style:Dome Camera
  • Audio Output:None
  • Megapixels:4MP
  • Sensor Brand:SONY
  • Dimensions (L x W x D)(mm):69.1 mm * 66 mm * 172.7 mm
  • Power Consumption(W):4W
  • TF Card:None
  • Storage:None
  • Brand Name:HIKVISION
  • Video Compression Format:H.264
  • Wall Bracket:Ceiling
  • Color:White
  • Connectivity:IP/Network Wired
