Specifications

General Specifications

Power Input

100 - 240 V ̴ 50/60 Hz

Signal-to-Noise Ratio

> 80dB

Output power (W)

200 W RMS (IEC60268)

Audio Specifications

Frequency Response

40 Hz - 20 kHz (-6dB)

Transducer - Tweeter (Inch)

2 x 1

Transducer - Woofer (Inch)

2 x 5.2

Transducer - Woofer (mm)

2 x 145

Transducer - Tweeter (mm)

2 x 25

Dimensions

Dimensions (Width x Height x Depth) (cm)

29.84 x 57.5 x 30.3

Dimensions (Width x Height x Depth) (in)

11.7 x 22.6 x 11.9

Weight (kgs)

11.3

Weight (lbs)

24.8

Control and Connection Specifications

Aux-In

355mV RMS (3.5mm connector)

Optical Input (dBFS)

-9

Bluetooth version

6.0

Portable Speaker Specs - Supported Music File Formats

MP3, WAV, FLAC

Bluetooth Profile

A2DP V1.4, AVRCP V1.6

Bluetooth Transmitter Frequency Range (GHz)

2.4 - 2.4835

Bluetooth Transmitter Modulation

GFSK, π/4 DQPSK, 8DPSK

Bluetooth Transmitter Power

≤ 18 dBm (EIRP)

Bluetooth Input (dBFS)

9

Guitar-In

100mV RMS

Mic-In

20mV RMS

USB Input (dBFS)

-9

Battery

Cable Length (ft)

6.6

Cable Length (m)

2

Cable Type

AC power cable (type varies by regions)

Battery Type

JBL BATTERY200, Li-ion 34 Wh (equivalent to 7.2V / 4722mAh)

Maximum music playing time (hrs)

15

Battery Charge Time (hours)

3

Features

Spill-proof

Yes

Smart EQ Mode

Yes

IP Code

IPX4

Dual Mic & Guitar inputs

Yes

Lightshow

Yes

Supports Auracast

Yes

Splashproof

Yes

AI Sound Boost

Yes

Playtime Boost

true

JBL One App

Yes
